Intel Pentium III 600 - RB80526PZ600256 (BX80526C600256 / BX80526C600256E)基本资料
类别:CPU 制造商:Intel
家族:Pentium III 产品:Intel Pentium III 600 - RB80526PZ600256 (BX80526C600256 / BX80526C600256E)
一般信息
类型 CPU / Microprocessor
细分市场 Desktop
系列
Intel Pentium III
型号    600EB
CPU部件号
  • RB80526PZ600256 is an OEM/tray microprocessor
  • BX80526C600256 is a boxed microprocessor
  • BX80526C600256E is a boxed microprocessor
频率    600 MHz
总线速度    133 MHz
时钟倍频器    4.5
封装 370-pin Flip-Chip Pin Grid Array (FC-PGA)
1.95" x 1.95" (4.95 cm x 4.95 cm)
接口 接口 370 / PGA370
发布时间 Oct 25, 1999
指导价格 $455
S规格号
部件号 ES/QS处理器 生产处理器
  QM49 QP12 SL3VB SL3VG SL3XT SL45V SL4CL SL5BR
BX80526C600256     +     +
BX80526C600256E     +   +   +
RB80526PZ600256 + + + + +   + +
架构 / 微体系结构
微体系结构 P6
处理器内核    Coppermine
核心步进    cA2 (QM49, SL3VB, SL3VG)
cB0 (QP12, SL3XT, SL45V)
cC0 (SL4CL)
cD0 (SL5BR)
CPUIDs 681 (SL3VB, SL3VG)
683 (SL3XT, SL45V)
686 (SL4CL)
制造工艺 0.18 micron
28 million transistors
模具尺寸 104.6mm2 (CPUID 0683h)
90mm2 (CPUID 0686h)
数据位宽 32 bit
Data bus width 64 bit
CPU核心数 1
线程数 1
浮点单元 Integrated
1级缓存大小    16 KB instruction cache
16 KB data cache
2级缓存大小    Full-speed integrated 8-way set associative 256 KB
多重处理 Up to 2 processors
特征
  • MMX instructions
  • SSE / Streaming SIMD Extensions
低功耗特性
  • AutoHALT state
  • Stop Grant state
  • Sleep state
  • Deep Sleep state
  • System Management Mode
电/热参数
Min/Recommended/Max V核 1.57V / 1.65V / 1.69V
1.62V / 1.7V / 1.74V
最小/最大工作温度    0°C - 82°C
Maximum power dissipation    20.4 Watt (1.7V核)
热设计功耗    15.8 Watt (CPUID 0686h)
Notes on Intel Pentium III 600EB (接口 370)
  • The processor is usually marked as 600EB/256/133/1.65V or 600EB/256/133/1.7V, where the last number specifies processor's core voltage. If the processor is marked with RB80526PZ600256 编号 then use processor specification number to identify processor's core voltage
  • Stepping cA2 CPUs for 接口 370 were not validated for dual-processing
Intel Pentium III 600 - RB80526PZ600256 (BX80526C600256 / BX80526C600256E)图片资料
Intel Pentium III 600 - RB80526PZ600256 (BX80526C600256 / BX80526C600256E)
